TECHNICAL SPECIFICATIONS
Engine & Performance Parameters
| Piston Displacement |
229cc |
| Bore x Stroke |
63 mm X 63.5 mm |
| Max. Power |
10.3 kW / 7500 rpm |
| Max. Torque |
14.2 N-m / 6000 rpm |
| Compression Ratio |
10.5 : 1 |
| Starting Method |
Electric Start & Kick Start |
| Clutch Type / Method |
Manual / Wet Multidisc (7-plates) |
| Lubrication Method |
Pressure and Splash |
| Lubricant Capacity
| 1 Liter (Max.) |
| Gear Shift Method |
Constant Mesh, Two-stage Transmission, 5-Speed Gearshift With Reverse Gear |
Suspension
| Front |
Heavy Duty 2 Shock Absorbers, 2 Dampers |
| Rear |
Two (7-Leaf) Leaf Springs, 2 Dampers |
Brakes
| Front Brake |
Mechanical (Brake shoes) |
| Rear Brake |
Hydraulic (Disk Type) |
Tyres
| Size |
135-10 : 10 PR |
| Type
|
Tube Type Rubber Tyres |
Fuel
| Fuel Type |
Gasoline (Petrol) / CNG |
| Gasoline Fuel Tank Capacity |
6.5 Liters |
| CNG Cylinder Capacity |
22 L – 30 L (WC) CNG Cylinder |
| Fuel Consumption - Gasoline |
28 - 30 Km / Liter |
| Fuel Consumption - CNG |
36 - 40 Km / Kg |
Electricals
Vehicle
| Frame Type |
Fabricated / C-Section Steel Channels |
| Roof Rack |
Not Included ; available in Prime model only |
|
| Hood Frame Construction |
Fabricated in 1 inch / 0.75 inch x 18/20swg Square / Round Pipe |
|
| Hood Apparel Material |
Beige / Blue / Green; Pearl Fancy Rexene / PU Coated Fabric |
|
| Unladen Weight |
470 kg |
| Load Bearing Capacity |
600kg |
| Wheel Base |
2350 mm (92.52 inches) |
| Wheel Track |
1110 mm (43.7 inches) |
| Overall Length |
3450 mm (135.82 inches) |
| Overall Width |
1300 mm (51.18 inches) |
| Overall Height |
2250 mm (88.58 inches) |
| Cargo Cabin |
310 mm / 390 mm x 1300 mm x 1930 mm |
| Turning Circle |
6900 mm (271.65 inches) |
| Gradeability |
12-13 % |
