TECHNICAL SPECIFICATIONS
Engine & Performance Parameters
Engine Type | 4-Stroke, Spark-Ignition, Single Cylinder, Liquid-Cooled |
Piston Displacement | 197cc |
Bore x Stroke | 63 mm X 63.5 mm |
Max. Power | 10.3 kW / 7500 rpm |
Max. Torque | 14.2 N-m / 6000 rpm |
Compression Ratio | 10.5 : 1 |
Starting Method | Electric Start & Kick Start |
Clutch Type / Method | Manual / Wet Multidisc (7-plates) |
Lubrication Method | Pressure and Splash |
Lubricant Capacity | 1 Liter (Max.) |
Gear Shift Method | Constant Mesh, Two-stage Transmission, 5-Speed Gearshift (4-Forward + 1-Reverse Gear) |
Suspension
Front | Heavy Duty 2 Shock Absorbers, 2 Dampers |
Rear | 2 Leaf Springs, 2 Dampers |
Brakes
Front Brake | Mechanical (Drum Type) |
Rear Brake | Hydraulic (Disk Type) |
Tyres
Size | 135-10 : 10 PR |
Type | Tube Type Rubber Tyres |
Fuel
Fuel Type | Gasoline (Petrol) / CNG |
Gasoline Fuel Tank Capacity | 6.5 Liters |
CNG Cylinder Capacity | 22 L – 30 L (WC) CNG Cylinder |
Fuel Consumption - Gasoline | 28 - 30 Km / Liter |
Fuel Consumption - CNG | 36 - 40 Km / Kg |
Electricals
Battery | 12V-S50(34Ah) |
Vehicle
Frame Type | Fabricated / C-Section Steel Channels |
Hood Frame Construction | Fabricated in 1-in x16/20swg Square / Round Steel Pipe |
Hood Apparel Material | Rexene / PVC or PU Coated Cloth / Canvas Cloth |
Unladen Weight | 435 kg |
Load Bearing Capacity | 600 kg |
Wheel Base | 2180 mm (85.82 inches) |
Wheel Track | 1115 mm (43.89 inches) |
Overall Length | 3000 mm (118.46 inches) |
Overall Width | 1220 mm (48 inches) |
Overall Height | 1900 mm (74.80 inches) |
Turning Circle | 6380 mm (251.18 inches) |
Gradeability | 16% |
